Daewoo TAC-07HRA/E1 - Page 18

Air Conditioner Service Manual
17
Indoor unit: TAC-09HRA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1080030003
Installation Plate
1
2
210738121
Base
1
3
210738389
Vertical Vane Assembly
2
4
210738131
Cross Fan
1
5
1070100010
Bearing Mount
1
6
211238000
Evaporator
1
7
210738120
Face Frame
1
8
210701846
Screw Cover
2
14
210738127
Vane
1
9
210738433
Air Filter
2
10
210705767
Display PCB Box
1
11
210901127S
Display PCB
1
12
210746847B
Front Panel
1
13
1170120044
Power Supply Cord
1
15
210738393
Electrical Box Cover
1
16
210900478A
Terminal
1
16
210736832
Cable Clamp
1
22
210901224
Transformer
1
17
210901617N
Main PCB
1
18
210736831
Electrical Box
1
23
210900333
Indoor Sensor Assembly
1
20
1170030047F
Indoor Motor
1
21
210737653
Indoor Motor Cover
1
15
210737091
Drainage Hose
1
19
1170020011
Vane Motor
1
24
210736813
In And Out Pipe Fixer
1
25
210900414NS
Remote Controller
1
Not shown in Explosion view
26
211368832G
Indoor Carton
1
27
211370972
Left Foaming
1
28
211370975
Right Foaming
1
