Daewoo TAC-07HRA/E1 - Page 19

Air Conditioner Service Manual
18
Indoor unit: TAC-12HRA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1080030003
Installation Plate
1
2
210737656
Base
1
3
210701880
Vertical Vane Assembly
2
4
210737655
Cross Fan
1
5
1070100010
Bearing Mount
1
6
211238554
Evaporator
1
7
210737662
Face Frame
1
8
210701846
Screw Cover
2
9
210737652
Vane
1
10
210701863
Air Filter
2
11
210705767
Display PCB Box
1
12
210901127S
Display PCB
1
13
210746792C
Front Panel
1
14
1170120045
Power Supply Cord
1
15
210737654
Electrical Box Cover
1
16
210900376
Terminal
1
17
210736832
Cable Clamp
1
18
210901510
Transformer
1
19
210901526AN
Main PCB
1
20
210736831
Electrical Box
1
21
210900333
Indoor Sensor Assembly
1
22
1170030047F
Indoor Motor
1
23
210737653
Indoor Motor Cover
1
24
210737091
Drainage Hose
1
25
1170020011
Vane Motor
1
26
210736813
In And Out Pipe Fixer
1
27
210900414NS
Remote Controller
1
Not shown in Explosion view
28
211367422CQ
Indoor Carton
1
29
211367583
Left Foaming
1
30
211367584
Right Foaming
1
