Indoor unit: TAC-18HRA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1080030021
Installation Plate
1
2
210738678
Base
1
3
210738575
Vertical Vane Assembly
2
4
1070020024AA
Cross Fan
1
5
1070100010
Bearing Mount
1
6
211237947
Evaporator
1
7
210738663
Face Frame
1
8
210701846
Screw Cover
2
9
210738661
Vane
1
10
210738606
Air Filter
2
11
210705767
Display PCB Box
1
12
210901127S
Display PCB
1
13
210746767C
Front Panel
1
14
1170120045
Power Supply Cord
1
15
210738393
Electrical Box Cover
1
16
210900376
Terminal
1
17
210736832
Cable Clamp
1
18
210901224
Transformer
1
19
210901617T
Main PCB
1
20
210736831
Electrical Box
1
21
210900333
Indoor Sensor Assembly
1
22
1170030067J
Indoor Motor
1
23
210738581
Indoor Motor Cover
1
24
210737091
Drainage Hose
1
25
1170020031AC
Vane Motor
1
26
210736813
In And Out Pipe Fixer
1
27
210900414NS
Remote Controller
1
Not shown in Explosion view
28
211370750N
Indoor Carton
1
29
211370968
Left Foaming
1
30
211370969
Right Foaming
1
