Daewoo TAC-07HRA/E1 - Page 37

Air Conditioner Service Manual
36
Outdoor unit: TACO-24HRA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1083520101
Back Grille
1
Optional
2
1081990056
Top Cover
1
3
211206428
Condenser
1
4
1081990060
Outdoor Motor Supporter
1
5
1170040100
Outdoor Motor
1
6
1070030040AA
Propeller Fan
1
7
1081990053
Left Grille Supporter
1
8
1081990258
Front Plate
1
9
1071990096
Fan Guard
1
10
211232872
Compressor
1
11
1120110017
4-way Valve
1
12
211238193
4-way Valve Assembly
1
13
210800568
Base
1
14
1081990054
Right Plate
1
15
1120120021
Two-way Valve
1
16
1081990055
Valve Supporter
1
17
1120130037
Three-way Valve
1
18
1070350971
Electrical Box Cover
1
19
1070040001
Cable Clampφ6
1
20
1070040008
Cable Clampφ10
1
21
1170500131
Terminal
1
22
1170100030A
Fan Motor Capacitor
1
23
1170100033A
Compressor Capacitor
1
24
1080010006
Capacitor Strip
1
25
1081990010
Electrical Parts Box
1
26
211238294
Capillary Assembly
1
27
1081990318
Partition plate
1
28
211312855NB
Cabinet Carton
1
Not shown in the Explosion view
29
211312854
Base Carton
1
30
211312852
Base Foaming
1
31
211312851
Cover Foam
1
