Outdoor unit: TACO-07HA/E2
No.
Part No.
Part Name
Q’ty
Remark
1
1071990038
Grille
1
Optional
2
1081990014
Top Cover
1
3
211232279A
Condenser
1
4
1081990018
Outdoor Motor Supporter
1
5
1170040071
Outdoor Motor
1
6
1070030006AA
Propeller Fan
1
7
1081990011
Left Grille Supporter
1
8
1081990016
Front Plate
1
9
1070251929
Fan Guard
1
10
1100110034
Compressor
1
11
1120110016
4-way Valve
1
12
211238951
4-way Valve Assembly
1
13
210837829
Base
1
14
1081990012
Right Plate
1
15
211236491
Two-way Valve
1
16
1081990013
Valve Supporter
1
17
1120130039
Three-way Valve
1
18
1073521301
Electrical Box Cover
1
19
1070040001
Cable Clamp(φ6)
1
20
1070040002
Cable Clamp(φ7)
1
21
1170500131
Terminal
1
22
1170100031A
Fan Motor Capacitor
1
23
1170100014A
Compressor Capacitor
1
24
1080010002
Capacitor Strip
1
25
1081990010
Electrical Parts Box
1
26
211238596
Capillary Assembly
1
27
1081990019
Partition plate
1
28
211313638
Base Carton
1
Not shown in Explosion
view
29
211313639YS
Cabinet Carton
1
30
211313637
Base Foaming
1
31
211313636
Cover Forming
1
