Outdoor unit: TACO-12HA/E2
No.
Part No.
Part Name
Q’ty
Remark
1
1071990039
Back Grille
1
Optional
2
1080320105
Top Cover
1
3
211238586
Condenser
1
4
1080050004
Outdoor Motor Supporter
1
5
1170040058
Outdoor Motor
1
6
1070030050AA
Propeller Fan
1
7
1080050001
Left Grille Supporter
1
8
210800274
Front Plate
1
9
1070251931
Fan Guard
1
10
1100011049
Compressor
1
11
1120110016
4-way Valve
1
12
211239753
4-way Valve Assembly
1
13
210800466
Base
1
14
1080050002
Right Plate
1
15
1120120021
Two-way Valve
1
16
1080050003
Valve Supporter
1
17
211206766
Three-way Valve
1
18
1070350971
Electrical Box Cover
1
19
1070040001
Cable Clamp(φ6)
1
20
1070040002
Cable Clamp(φ7)
1
21
1170500131
Terminal
1
22
1170100010AB
Fan Motor Capacitor
1
23
1170100004A
Compressor Capacitor
1
24
1080010006
Capacitor Strip
1
25
1081990010
Electrical Parts Box
1
26
211204774
Capillary Assembly
1
27
1081990314
Partition plate
1
28
211369052
Base Carton
1
Not shown in the Explosion view
29
211311098AHU
Cabinet Carton
1
30
211311099
Base Foaming
1
31
211311100
Cover Forming
1
