Outdoor unit: TACO-18HA/E2
No.
Part No.
Part Name
Q’ty
Remark
1
1071990040
back Grille
1
Optional
2
1080050011
Top Cover
1
3
211200883A
Condenser
1
4
1080050004
Outdoor Motor Supporter
1
5
1170040059
Outdoor Motor
1
6
1070030038AA
Propeller Fan
1
7
1080050001
Left Grille Supporter
1
8
210800275
Front Plate
1
9
1070251931
Fan Guard
1
10
211238303
Compressor
1
11
1120500226
4-way Valve
1
12
211238305
4-way Valve Assembly
1
13
210800487
Base
1
14
1080050002
Right Plate
1
15
1120120021
Two-way Valve
1
16
1080050003
Valve Supporter
1
17
1120130085
Three-way Valve
1
18
1070350971
Electrical Box Cover
1
19
1070040001
Cable Clamp(φ6)
1
20
1070040003
Cable Clamp(φ8)
1
21
1170500131
Terminal
1
22
1170100027A
Fan Motor Capacitor
1
23
1170100004A
Compressor Capacitor
1
24
1080010006
Capacitor Strip
1
25
1081990010
Electrical Parts Box
1
26
211204878
Capillary Assembly
1
27
210800557
Partition plate
1
28
211369053
Base Carton
1
Not shown in the Explosion view.
29
211311128ADE
Cabinet Carton
1
30
211311130
Base Foaming
1
31
211311129
Cover Forming
1
