Air Conditioner Service Manual
42
Outdoor unit: TACO-28HRA/E1
No.
Part No.
Part Name
Q’ty
Remark
1
1071990041
Grille
1
Optional
2
1081990038
Top Cover
1
3
211238231
Condenser
1
4
1081990042
Outdoor Motor Supporter
1
5
1170040102
Outdoor Motor
1
6
1170120146AA
Propeller Fan
1
7
1081990040
Left Grille Supporter
1
8
1081990047
Front Plate
1
9
1070251945
Fan Guard
1
10
1100011034
Compressor
1
11
1120110017
4-way Valve
1
12
211238746
4-way Valve Assembly
1
13
1081990178
Base
1
14
1081990039
Right Plate
1
15
1120120021
Two-way Valve
1
16
1081990041
Valve Supporter
1
17
1120130037
Three-way Valve
1
18
1070350971
Electrical Box Cover
1
19
1074060118
Cable Clamp
1
20
1170200054
Terminal
1
21
1170100030A
Fan Motor Capacitor
1
22
1170100025A
Compressor Capacitor
1
23
1080010006
Capacitor Strip
1
24
1081990049
Electrical Parts Box
1
25
1174561801
AC Contactor
1
27
211238239
Capillary Assembly
1
28
1081990050
Partition plate
1
29
1190500707BKH
Cabinet Carton
1
Not shown in the Explosion view
30
211310615
Upper Foaming
1
31
211310616
Base Foaming
1
32
1190060191
Base Carton
1
