Daewoo TAC-07HRA/E1 - Page 44

Air Conditioner Service Manual
43
Outdoor unit: TACO-36HA/WE
No.
Part No.
Part Name
Q’ty
Remark
1
1071990055
Grille
1
Optional
2
1080050045
Top Cover
1
3
211231303A
Condenser
1
4
210800644
Outdoor Motor Supporter
1
5
210900509
Outdoor Motor
1
6
210702407
Propeller Fan
1
7
1080050042
Left Grille Supporter
1
8
210800337
Front Plate
1
9
210702363
Fan Guard
1
10
211233665
Compressor
1
11
1120110021
4-way Valve
1
12
211233791
4-way Valve Assembly
1
13
210826467
Base
1
14
1080050043
Right Plate
1
15
1120120033
Two-way Valve
1
16
1080050044
Valve Supporter
1
17
1120130045
Three-way Valve
1
18
1070350971
Electrical Box Cover
1
19
1074060118
Cable Clamp
1
20
1170200054
Terminal
1
21
1170100067A
Fan Motor Capacitor
1
22
210901177
Compressor Capacitor
1
23
1080850106
Capacitor Strip
1
24
1080050056
Electrical Parts Box
1
25
1174561801
AC Contactor
1
26
211233798
Capillary Assembly
1
27
1170230005
Outdoor Sensor
1
Not show in the explosion view
28
211367224EG
Cabinet Carton
1
29
211367222
Upper Carton
1
