DAF CF65 - Drive and Chassis

©
200518 3-1
Drive and chassis
TECHNICAL DATA
ΧΦ65/65 (II) series
0
3. DRIVE AND CHASSIS
3.1 GENERAL
Allison gearbox
The Allison MD3060 automatic gearbox is
electronically controlled. The oil level can be read
out via the selector keypad. This keypad is
located next to the driver's seat. The oil level can
also be checked using the dipstick.
Dipstick readings:
The oil level when cold must be on the "Cold full"
mark.
R
D
MODE
N
V300392
HOT
FULL
COLD
FULL
HOT
ADD
COLD
ADD
W 3 03 099
"Cold add" add when cold
"Cold full" full when cold
"Hot add" add when hot
"Hot full" full when hot
