EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-36
©
200518
Inspection and adjustment
5
ΧΦ65/65 (II) series
Checking oil level with selector keypad
1. Apply the parking brake, put the gearbox in
neutral and bring the gearbox to operating
temperature (approx. 71ºC - 93ºC).
2. Run the engine at idling speed for 2 minutes.
3. Press both arrow keys on the selector
keypad simultaneously. The display now
shows the letters O and L.
Note:
O and Lstand for Oil Level.
4. When the oil level is correct, the letters O - K
appear on the display.
When the oil level is too high, this is indicated
by HI followed by the number of litres in
excess.
When the oil level is too low, this is indicated
by LO followed by the number of litres
lacking.
For example:
LO-02 means that two litres have to be
added.
HI-03 means that three litres have to be
drained.
R
D
MODE
N
V300392
