EXTERNAL CAB COMPONENTS
Removal and installation LF45/55 series
4-6
4.5 REMOVAL AND INSTALLATION, CORNER PIECE
Removing the corner piece
1. Open the grille and remove the attachment
bolts (1).
K1 00 982
2. Open the door and remove the attachment
bolts (1).
3. Remove the corner piece (2).
Installing the corner piece
1. Fit the corner piece.
2. Secure the corner piece (2) in the door post
and at the front of the cab, using the
attachment bolts (1).
3. Close the grille.
K1 00 983
4.6 REMOVAL AND INSTALLATION, LATTICE GRILLE
Removing the lattice grille
1. Open the grille.
2. Remove the attachment bolts from the
lattice.
3. Remove the lattice.
Fitting the lattice grille
1. Fit the lattice.
2. Secure the lattice using the attachment
bolts.
3. Close the grille.
K1 00 991
