LF45/55 series Removal and installation
INTERNAL CAB COMPONENTS
4-35
4.16 REMOVAL AND INSTALLATION, REAR WALL LINING
Removing the rear wall lining
Note:
When working on the upholstery make sure
hands are clean or wear gloves.
1. Remove the panel clips on the rear wall of
the cab.
2. If applicable, remove the thermostat and
clock from their casing using a small
screwdriver.
3. Remove the rear wall supports.
4. Remove the (entrance) grip.
5. Remove the rear wall lining. Pay attention
to the connectors for the cab heater sensor
and lighting.
Installing the rear wall lining
1. Fit the rear wall using the panel clips. Pay
attention to the connectors for the cab
heater sensor and lighting.
2. Fit the (entrance) grip.
3. Fit the supports to the rear wall.
4. Fit the thermostat and clock if applicable.
2
ǹ 0210
