CAB HEATING
Removal and installation LF45/55 series
3-10
3.4 REMOVAL AND INSTALLATION, HEATER MOTOR
Removing the heater motor
1. Remove the fire extinguisher, if applicable.
2. Remove the dashboard panel on the engine
tunnel.
3. Remove the ashtray and the ashtray holder.
Take out the cigarette lighter connector and
remove the ashtray lighting.
4. Remove the connectors from the heater
cover.
5. Remove the cover attachment bolts and put
the cover aside.
K1 00 953
6. Remove the connectors from the series
resistor.
If applicable, remove the connectors from
the air conditioning thermostat.
K1 00 954
7. Remove the cover.
3
ǹ 0210
