LF45/55 series General
CAB TILTING GEAR
2-1
2. GENERAL
2.1 SYSTEM DESCRIPTION, CAB TILTING MECHANISM
General
The cab is equipped with a hydraulic tilting gear .
The pump is on co-driver side behind the
stepwell.
The cab locks are automatically released during
pumping.
The hydraulic locking mechanism has a switch
on one side, to activate the warning light for
tilted cab (in the instrument panel).
If the vehicle has been involved in a collision,
check the following points before tilting the cab.
- cab rests,
- cab hinges,
- attachment of the lifting cylinder,
- hydraulic system for leakage.
After this check, continue to proceed with
utmost care.
If possible, suspend the cab in slings and put a
stand in front of the cab.
After a collision, always check the lifting cylinder
for internal damage.
Tilting the cab:
- Make sure there are no people immediately
in front of the cab.
- Make sure there is sufficient clearance
around the cab.
- Make sure there are no loose objects inside
the cab.
- Apply the parking brake.
- Move the gear lever to the right position
and turn off the engine.
- Close the doors.
- Turn the cab-tilting pump cock as far to the
right as possible.
- Position the rod in the pump and operate
the pump.
You can stop the cab tilting forward at any
time by turning the cock anticlockwise.
