1SEATS
Removal and installation LF45/55 series
4-2
6. Fit the seat belt tensioner connector.
7. Connect the batteries.
4.2 REMOVAL AND INSTALL ATION, SEAT SLIDE
Removing seat slide
1. Remove the seat assembly.
2. Slide both seat slides forwards until the rear
attachment screws (1) can be reached
through the holes (2) in the slide.
3. Remove the rear attachment screws.
4. Slide the seat slides backwards.
5. Remove the front at tachment screws (3).
6. Take the seat slides off the seat frame.
Installing seat slide
1. Fit the seat slides to the seat frame using
the front attachment screws (3).
2. Fit the rear attachment screws (2) through
the mounting holes in the seat slides (1).
3. Install the seat assembly.
3
1
2
K1 01 379
4.3 REMOVAL AND INSTALL ATION, SEAT ADJUSTING MECHANISM
Removing seat adjusting mechanism
1. Slide the seat into the frontmost position.
2. Press the bracket (1) of the seat adjusting
mechanism out of the attachment clamp (2)
and the supporting cams (3).
Installing seat adjusting mechanism
1. Press the seat adjusting mechanism
bracket (1) on either side into the
attachment clamps (2) and the supporting
cams (3).
3
3
2
1
K1 01 380
7
ǹ 0210
