1
INTERNAL CAB COMPONENTS
Removal and installation LF45/55 series
4-4
Removing the upper cover
1. Remove the attachment bolts at the bottom
of the cover.
2. Remove the cover from the upper cover
panel by tilting it upwards.
K1 01 433
Removing the central console control panel
1. Remove the switches (3) from the control
panel in the central console (5).
2. Remove the ashtray (2) from the control
panel in the central console (5).
3. Remove the attachment bolts (1) from
control panel in the central console (5).
4. Remove the control panel from the central
console (5).
5. Disconnect the connector of the cigarette
lighter (4).
1
1
K1 01 434
2
3
4
5
Removing the right-side dashboard panel
1. Remove the dashboard panel attachment
bolts.
2. Remove the connector from the stepwell
lighting door switch
K1 01 435
2
ǹ 0210
