0
1
LF45/55 series Internal and external cab components
TECHNICAL DATA
1-5
M
N K
L
G
H
BCE
J
I
ADF
K1 01 210
Cab front dimensions
A - B 836 mm
C - D 836 mm
E - F 836 mm
G - I 1973 mm
H - J 1973 mm
Front panel dimensions
N - L 1945 mm
K - M 1945 mm
ǹ 0210
