TECHNICAL DATA
2-2
©
200423
Steering gear and brake system
0
ΞΦ95 series
2.2 TIGHTENING TORQUES
Steering gear
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques. The other threaded connections not
specified must therefore be tightened to the
torque stated in the overview of standard
tightening torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Note:
- The two plugs are interchangeable.
(1) Fit new original attachment bolt and nut.
A
S7 00 906
Filter plug without flange (A),
fluid flow control valve block
of EMAS system 125 Nm ≥ 5 Nm
B
S7 00 907
Filter plug with flange (B),
fluid flow control valve block
of EMAS system 270 Nm ≥ 20 Nm
Attachment bolt, steering column universal joint 54 Nm + 4 Nm
(1)
