EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-30
©
200423
Inspection and adjustment
5
ΞΦ95 series
3.30 INSPECTION, FLUID LEVEL OF HYDRAULIC TRAILING-AXLE DEVICE
1. Make sure that the trailing axle wheels are
fully lowered and on the ground.
2. Check the fluid level. The liquid level must be
between the "min." and "max." level mark. If
necessary, top up.
3.31 INSPECTION, PIVOT POINTS OF THE HYDRAULIC TRAILING-AXLE DEVICE
1. Check the play on the pivot points when
operating the hydraulic trailing axle.
3.32 CHECKING THE DIFFERENTIAL FOR LEAKS
1. Visually inspect the differential for leaks.
