200423 3-23
Inspection and adjustment
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
ΞΦ95 series
5
Version: Knorr SN 7000
1. Check the transition between the ribbed part
of the rubber cover and the smooth part (A).
If the smooth part is rolled inwards, the brake
shoe and brake disc thicknesses must be
checked.
A
A
A
R600730
