Dahua Technology DH-TPC-BF5421-T - Installation Diagram 1

Installation Guide
© 2019 Dahua. All rights reserved. Design and specifications are subject to change without
notice. Pictures in the document are for reference only, and the actual product shall prevail.
• The area needs to be
defined and marked
clearly with pullout
safety barriers or similar.
• The flow of People
should, in this case,
begin from the left and
exit in the bottom right
side, it could be
opposite as long as
diagram 2 is followed.
Installation Diagram
1
