Installation Guide
© 2019 Dahua. All rights reserved. Design and specifications are subject to change without
notice. Pictures in the document are for reference only, and the actual product shall prevail.
Poe Switch
5 Port
DH-TPC-BF5421
230V
Ethernet Cable
• Connect the Camera to
port 1 in the PoE switch
with the ethernet cable
provided.
• Connect the IVSS Server
with the Ethernet cable
provided to port 1 and
the PoE switch to port 5.
• All the connections
should look like the
picture to the right.
IVSS7008-1I Server
230V
Ethernet Cable
Wiring the devices
15
