User’s Manual
3
5 Installation
Prior to installation, add the keypad to the hub and check the signal strength of the installation
location. We recommend installing the keypad in a place with a signal strength of at least 2 bars.
The keypad supports wall mount.
Step 1 Loosen the screw to open the keypad.
Figure 5-1 Loosen the screw
Figure 5-
2 Open the keypad
Step 2 I
nsert four batteries into the keypad.
If the battery is dead, you need to replace the battery.
When replacing the battery, make sure that the side marked with "
" faces the back
cover of the keypad.
Make sure to use the same model when replacing the battery to avoid fire or explosion.
Make sure not to mix the old batteries with new one.
Figure 5-3 Put on the batteries
Step 3 D
rill four holes in the wall according to the hole positions of the keypad, and then put the
expansion bolts into the holes.
