User’s Manual

Analog channel

Digital channel

Table 5-11 Live control bar description

No.

Function

No.

Function

No.

Function

1 Instant Playback 4 Manual Snapshot 7 Camera Registration

2 Digital Zoom 5 Mute / /

3 Instant Record 6 Audio Talk / /
