User’s Manual
7
Fix other disks on the bracket as needed.
Fix other disks
Fix the two drive brackets.
This is only needed on models with 8 bays.
Fix drive brackets
Put the drive brackets back and fix them in the DVR.
Put back drive bracket
Connect the disks and the DVR with power cable and data cable.
The following figure shows the connection of 4-bay model for example.
