User’s Manual
270
Table 5-48 Recognized information
NIC Name Displays the name of Ethernet card.
Network Type Displays the network type. Different type represents different supplier.
APN Displays the default APN number.
Dial-up No. Displays the default dial No.
Authentication
Type
Authentication mode. You can select
,
, or
.
Username,
Password
Enter the username and password for authentication.
Select the Enable checkbox.
Click Dial to start connecting.
After the connection is established, the result is displayed in the Wireless Network area.
Wireless network
Click Apply to complete the settings.
5.15.1.5 Configuring PPPoE Settings
PPPoE is another way for the Device to access the network. You can establish network connection by
configuring PPPoE settings to give the Device a dynamic IP address in the WAN. To use this function,
firstly you need to obtain the username and password from the Internet Service Provider.
Select Main Menu > NETWORK > PPPoE.
