13
3 Simple GUI Operation
Connect the device to the monitor and then connect a mouse and power cable. Click the power button at
the rear panel and then boot up the device to view the analog video output. You can use the mouse to
implement some simple GUI operation.
3.1 Login
After device booted up, the system is in multiple-channel display mode. See Figure 3-1. Please note the
displayed window amount may vary. The following figure is for reference only.
You can overlay the corresponding date, time and channel name on each screen. You can refer to the
following sheet for channel record or alarm status information.
Figure 3-1
Right click mouse, you can see the login interface. Please input user name and password. See Figure 3-2.
System consists of four accounts:
z Username: admin. Password: admin.
z Username: 888888. Password: 888888.
z Username: 666666. Passwords: 666666.
z Username: default. Password: default.
You can use USB mouse to input. Click
to switch between numeral, English character
(small/capitalized) and denotation.
1
Recording status
3
Video loss
2
Motion detection
4
Camera lock
