1.4.2 38 Series
① Use the screwdriver to loose the screws of the rear panel and then remove the front cover.
② Put the HDD to the HDD bracket in the chassis and then line up the four screws to the four holes in the
HDD. Use the screwdriver to fix the screws firmly to secure HDD on the HDD bracket
③ Connect to the HDD data cable to the main board and the HDD port respectively. Loosen the power
cable of the chassis and connect another end of the power cable to the HDD port.
4. Turn the device upside down
and then turn the screws in
firml
y
.
5. Fix the HDD firmly.
6. Connect the HDD cable and
power cable.
7. Put the cover in accordance
with the clip and then place the
upper cover back.
8. Secure the screws in the
rear panel and the side panel.
