24
4 Web Client Operation
Slightly difference may be found in the interface due to different series.
4.1 Network Connection
Before web client operation, please check the following items:
z Network connection is right
z NVR and PC network setup is right. Please refer to network setup.
z Use order ping ***.***.***.***(* NVR IP address) to check connection is OK or not. Usually the return
TTL value should be less than 255.
z System can automatically download latest web control and the new version can overwrite the previous
one.
z If you want to un-install the web controls, please run uninstall webrec2.0.bat to auto delete the control
or you can go to C:\Program Files\webrec to delete Single folder.
4.2 Login
Open IE and input NVR address in the address column. For example, if your NVR IP is 10.10.3.16, then
please input http:// 10.10.3.16 in IE address column.
System pops up warning information to ask you whether install webrec.cab control or not. Please click yes
button.
If you can’t download the ActiveX file, please modify your IE security setup.
After installation, the interface is shown as below. See Figure 4-1.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Figure 4-1
4.3 Main Window
After you logged in, you can see the main window. See Figure 4-2.
Click the channel name on the left side; you can view the real-time video.
For detailed operation information, please refer to the User’s Manual included in the resources CD.
