1 Hardware Installation and Connection
Note: All the installation and operations here should conform to your local electric
safety rules.
1.1 Check Unpacked NVR
When you receive the NVR from the forwarding agent, please check whether there is any visible damage.
The protective materials used for the package of the NVR can protect most accidental clashes during
transportation. Then you can open the box to check the accessories.
Please check the items in accordance with the list (Remote control is optional). Finally you can remove the
protective film of the NVR.
1.2 About Front Panel and Rear Panel
For detailed information of the function keys in the front panel and the ports in the rear panel, please refer
to the User’s Manual included in the resource CD.
The model label in the front panel is very important; please check according to your purchase order.
The label in the rear panel is very important too. Usually we need you to represent the serial number when
we provide the service after sales.
1.3 After Remove the Chassis
Please check the data cable, power cable, COM cable and main boar cable connection is secure or not.
1.4 HDD Installation
You can refer to the User’s Manual for recommended HDD brand. Please use HDD of 7200rpm or higher.
Usually we do not recommend the PC HDD.
Please follow the instructions below to install hard disk.
1.4.1 32 Series/32-P Series/32-S Series
1. Loosen the screws of the
u
