Dahua DH-EPC430U-PTZ-IR

Explosion-proof Integrated PTZ & Camera-Instruction Manual
10
2.5.2. Cable specification
A comprehensive cable is provided on packaged product (see Table 2.5.2 for cable
specification), the cable is lead out from the side of the base bottom with minimum length of
2m; connect the comprehensive cable to the system bus in the junction box before operation.
Table 2.5.2 Cable specification
Part name
Color
Function
Alarm audio 485(optional)
purple
Audio output
black
Audio grounding
white-purple
Audio input
blue-white
Alarm input 1
blue
Alarm input 2
black-white
Alarm input grounding
orange
Alarm output 1(COM1)
orange-white
Alarm output 2(OUT1)
yellow
485 output A
white
485 output B
Fast Ethernet
orange-white
Network cable 1
orange
Network cable 2
green-white
Network cable 3
blue
Network cable 4
blue-white
Network cable 5
green
Network cable 6
brown-white
Network cable 7
brown
Network cable 8
Power
thick brown
100-240V AC
24V AC(optional)
thick yellow-green
Grounding
thick blue
100-240V AC
24V AC(optional)
2.5.3. Parameter setting
Open the rear cover with inner hexagon spanner will find the toggle switch, see Figure 2.5.3.1.
