Local Configurations 114
Figure 5-73
Configure the settings for the covered area parameters. See Table 5-27. Step 2
In the Channel list, select the channel that you want to configure the
settings for.
Preview: Select the Preview check box to apply the configured
covered block to the selected channel window in the live view
screen.
Record: Select the Record check box to apply the configured
covered block to the selected channel window during recording.
To configure covering block, do the following:
1. Select the Preview check box or the Record check box, or select
the both. The "1, 2, 3, 4" buttons are activated.
2. Click the buttons to select blocks.
A triangle solid black block is displayed.
3. Drag the block to the area that you want to cover and adjust the
size of the block. You can configure total 4 covered blocks.
Table 5-27
Click Apply to complete the settings. Step 3
5.5.5 Configuring Channel Type
You can configure the channel type as Analog or IP channel.
Select Main Menu > CAMERA > CHANNEL TYPE. Step 1
