Local Configurations 174
Enter the customized rule name.
Configure the minimum time period for activating alarms by
detecting the abandoned objects.
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and
minimum size). When the target that is crossing the tripwire is
smaller than the minimum size or larger than the maximum size, no
alarms will be activated. The maximum size should be larger than
the minimum size.
In the Preset list, select the preset that you want to configure the
rule for.
Table 5-47
Drag to draw an area. 4)
Click OK to save the settings. 5)
Click to set the actions to be triggered. For details, see "5.11.1.1 Configuring Step 3
Tripwire Rules."
Select the Enable check box, and then click Apply. Step 4
The abandoned object detecting function is active. When the object is placed in the
defined detection area for more than the set time, the system activates alarms.
5.11.1.4 Configuring Missing Rules
When the target is taken away from the defined area exceeds the set time, the system activates
alarms.
On the rule line that you added, in the Type list, select Missing. Step 1
The Missing interface is displayed. See Figure 5-145.
