Dahua DH-XVR5216A-X User Manual

Local Configurations 179
Select Main Menu > SMART DETECTION > SMART SEARCH > SMD. Step 1
The SMD interface is displayed. See Figure 5-141.
Figure 5-141
Select channel, type, begin time and end time, and then click Search. Step 2
The search result is displayed. See Figure 5-142.
 Click to play back the video.
 Tick the check box before the video, and then click Export to export the video to
external USB.

Dahua DH-XVR5216A-X Specifications

General

Compression Format	H.265+/H.265/H.264+/H.264
Smart Fan	Yes
Operating System	Embedded Linux
USB Interface	2 x USB 2.0
Operating Humidity	10% to 90%
Video Input	16-channel
Video Output	1 HDMI, 1 VGA
Storage Capacity	Up to 10TB
Network Interface	1 RJ-45 port (10/100/1000 Mbps)
Audio Input/Output	1 x RCA in, 1 x RCA out
Max IP Camera Input	16-channel
Hard Drive Support	SATA HDD
HDD Slots	2
Alarm Input	16
Operating Temperature	-10°C to +55°C
