3.1.5 DH-XVR4216AN-X/DH-XVR4232AN-X/DH-XVR5216AN-X/D
H-XVR5232AN-X/DH-XVR5208AN-4KL-X/DH-XVR5216AN-4KL-X/
DH-XVR5216A-X
Figure 3-5
No.
Port Name
Function
1
Status indicator light
Glows blue when the device is working properly.
2
HDD
Glows blue when HDD status is abnormal.
3
NET
Glows blue when network status is abnormal.
4
POWER
Glows blue when the power is connected properly.
5
USB port
Connects to the external devices such as keyboard, mouse,
and USB storage device.
Table 3-5
3.1.6 DH-XVR7208A-4KL-X/DH-XVR7216A-4KL-X/DH-XVR7208A-
4K-X
Figure 3-6
No.
Port Name
Function
1
Status indicator light
Glows blue when the device is working properly.
2
USB port
Connects to the external devices such as keyboard, mouse,
and USB storage device.
Table 3-6
