User's Manual
1
1 Introduction
1.1 Overview
Alarm hub is a central device in the security system, which controls the operation of all connected
accessories. If the security system detects the presence, entry, or attempted entry of an intruder into
the armed area, the hub will receive the alarm signals from the detectors, and then alert users.
1.2 Technical Specifications
This section contains technical specifications of the device. Please refer to the ones that correspond
with your model.
Table 1-1 Technical specifications
Type Parameter Description
Port
Network 1 RJ-45 10 M/100 M self-adaptive Ethernet port
GSM Single SIM (GSM:900/1800 MHz); dual SIM single standby
LTE
Single SIM (GSM: 900/1800 MHz, WCDMA: B1/B5/B8, LTE-FDD:
B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41); dual SIM single
standby
Battery 12 V battery port
Indicator Light
1 for multiple statuses (alarm, arming, disarming, networking,
and malfunction)
Button 1 × reset, 1 × power, 1 × AP
Buzzer Built-in
Tamper 1 case tamper port for the alarm control panel
Function
SMS Notification
SMS alarm (up to 5 phone numbers)
Only available on select models.
Phone Call
Notification
Yes (up to 5 phone numbers)
Only available on select models.
Video Linkage Yes
Network Protocol TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP
Remote Upgrade Cloud update
Configuration
Method
App
Arm and Disarm
Method
App, keypad, keyfob, schedule
