Dahua DHI-NVR4216-4KS2 - 3 Connection

Connection 6
3 Connection
Following figures are for reference only. The actual product shall govern.
1U series connection Figure 3-1
 Check the icons on the rear panel carefully and refer to the actual product for detailed
information.
 If the icon is , input DC 12V power. If the icon is , input DC 48V power.
