Dahua IPC-HFW5100C User Manual

3
Support customized
setup.
Video Flip
Support mirror and flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
Manual 2.8~12mm
@F1.4
Manual
3.3~12mm@F1.4
Motorized
3~9mm@F1.4
Lens Interface
Φ14. Lens is the default accessories
Audio
Audio Input
1-channel,RCA
Audio Output
1-channel, RCA
Bidirectional
Talk Input
Reuse the first audio input channel
Audio Bit Rate
16kbps 16BIT
Audio
Compression
Standard
G.711A/G.711Mu/PCM
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Alarm Input
2-channel input,1-channel output
Record and Backup
Record Priority
Manual>External alarm >Video detect>Schedule
Local Storage
Support Micro SD card hot swap
Storage
Management
Support display local storage status
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
AUX
Interfa ce
Video Output
1-channel analog video output,BNC port
Reset
Reset button
General Parameter
Power
AC 24V/PoE or DC 12V/PoE
Power
Consumption
7.5W MAX (-H series≤9W)
8.5W MAX (-H series
≤11.5W, PoE (AT
standard))
Working
Temperature
-30℃~+60℃(-H: -40°~60°)
Working
Humidify
≤95%
Dimensions(mm)
φ104×306.7
Weight
1250g(Excluding box)
Installation
Bracket is included as default.
IR Distance
20~30m
Protection Level
IP66
Note
Model with “-H” means it has electrical heating, otherwise, it does not
