Page #8 background imageLoading...
Page #8 background image
2
Log function
Support system resource information and running status real-time display.
Day/Night mode auto switch.
Built-in IR light. Support IR night vision.
Support picture parameter setup such as electronic shutter and gain setup.
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support video watermark function to avoid vicious video modification.
The enclosure conforms to the IP 66 protection. Has the waterproof function.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for network camera performance specification.
Model
Parameter
IPC-HFW5100C(-H)
IPC-HFW5200C(-H)
IPC-HFW5202C(-H)
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Micro SD card status, bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3.0-inch CMOS
1/2.9-inch CCD
Pixel
1280(H)*960(V)
1920(H)*1080(V)
Day/Night Mode
Support day/night mode switch and IR-CUT at the same time.
Auto Aperture
Enable
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Off/BLC(default or custom)/WDR (0-100 adjustable)/HLC(0-100
adjustable)
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream
(1.3M@25fps,
720P@25fps)
extra stream
(D1@25fps,
CIF@25fps)
PAL:
Main stream (1080P@25fps),
extra stream (D1@25fps, CIF@25fps)
NTSC:
Main stream
(1.3M@30fps,
720P@30fps)
extra stream
(D1@30fps,
CIF@30fps)
NTSC:
Main stream (1080P@30fps),
extra stream (D1@30fps, CIF@30fps)
Video Bit Rate
H.264: 32-8192Kbps
adjustable
MJPEG: 32-
12288Kbps
adjustable and bit rate
is adjustable.
H.264: 32-8192Kbps adjustable
MJPEG: 32-16384Kbps adjustable and bit rate
is adjustable.
Support customized setup.
