Dahua IPC-KW10 User Manual

HD Cube Network Camera User’s Manual
7
SN
Port Name
Indicator
Connector
Note
3
PIR sensor
-
/
Passive IR motion detect port. It
can detect the IR object movement
(such as human body or other
heating object).
Note:
Only certain series have this
function.
4
IR light
/
/
For lighting at night
5
Speaker
/
/
Output audio signal.
(This function is optional. For some
series product only.)
6
Microphone
/
/
Directly receive audio signal.
7
Micro SD card
Micro SD
Micro SD
card slot
SD card storage.
(This function is optional. For some
series product only.).
8
Network port
LAN
Ethernet port
Connect to standard Ethernet
cable.
Note:
Some models do not support PoE.
9
Power port
DC12V
/
Input DC 12V power.
10
Reset/WPS
button
Reset/WPS
When device works normally:
 Press the WPS button of the
router and the device
respectively for at least 2
seconds. Usually the device
can connect to the router.
(Optional function supported by
some series)
 Press the button for 10s,
device restores default
settings.
11
Alarm port
-
I/O port
Alarm info input/output (optional,
supported by some models only)
Port Name
SN
Name
Note
I/O Port
1
ALARM_COM
Alarm output port. It is to output the alarm signal
to the alarm device.
2
ALARM_NO
Idle
3
GND
Ground port
4
ALARM_IN
Alarm input port. It is to receive the on-off signal
from the external alarm source.

Dahua IPC-KW10 Specifications

General

Brand	Dahua
Model	IPC-KW10
Category	Security Camera
Language	English
