Dahua KTA02 User Manual

2
Table 1-1 Front panel
No.
Icon
Description
1
–
Microphone.
2
Press to hang up the incoming call.
3
Bring up the menu.
4
When someone is calling from the door station:
 Press once to do voice communication with the person.
 Press twice quickly to hang up.
5
 When someone is calling from the door station, press to do voice
communication with the person.
 When no one is calling, press once, twice, three times and four times to
view live video of: door station 1, door station 2, analog camera 1 and
analog camera 2 respectively.
6
When someone is calling, press to open the door where the door station is
installed.
7
–
Power indicator.
8
–
LCD screen.
9
–
Microphone.
10
–
Built-in camera.
11
–
Power indicator.
12
–
Call button.
 Press once to call indoor monitor.
 Press and hold for 10 seconds to change the bell type of the door
station. The power indicator will flash.
 Press and hold for 15 seconds to turn up the bell volume of the door
station. The power indicator will flash. When the volume reaches
maximum, this step will set it to minimum. Repeat this step to set
appropriate volume.
 Press and hold for 20 seconds to change to DWDR (digital wide
dynamic range)/normal mode of the door station. The power indicator
will flash.
13
–
Speaker.

Dahua KTA02 Specifications

General

Model	KTA02
Category	Intercom System
System	Embedded Linux
Network Protocol	TCP/IP
Installation	Wall-mounted
Tamper Switch	Yes
Card Type	IC card
Network	10/100M Ethernet
Power Supply	DC 12V
Operating Humidity	10%–90% (RH), non-condensing
Unlock Mode	Card, password, remote
Exit Button	1
Door Contact Detect	1
Lock Control	1
