User's Manual
96
Figure 5-62 Snapshot
Step 2 Configure parameters.
Table 5-20 Snapshot parameters
Select the number of snapshots that you want to take each time.
Select the channel that you want to configure the settings for.
●
Scheduled: The snapshot is taken during the scheduled period.
●
Event: The snapshot is taken for motion detection, video loss,
local alarms and other events.
The size is determined by the resolution of the main stream or sub
stream of the channel.
Configure the image quality. The higher the level is, the better the
image will become. Level 6 represents the best quality.
Select or customize how frequently snapshots are to be taken.
