System Configurations 42
New TV Wall
Click . Step 1
The New TV Wall dialog box pops up. See Figure 4-33.
New TV wall Figure 4-33
Enter the name, select line and column, and then click . Step 2
Drag decoding channels on the right into the screen to bind them. Step 3
(Optional) Select two or more screens, and then click to merge them into one Step 4
screen.
Click . Step 5
Delete TV Wall
Click to delete TV wall.
Cancel Merged Screen
Select a merged screen and then click .
Edit TV Wall
Click and the Edit TV Wall dialog box is displayed. See Figure 4-34.
