Figure 5-219 TCP/IP
Table 5-58 TCP/IP parameters
Parameter
Description
Network Mode
●
Single NIC : The current NIC card works independently. If the current
NIC card is disconnected, the Device becomes oine.
●
Fault Tolerance: Two NIC cards share one IP address. Normally only
one NIC card is working. When this card fails, the other NIC card will
start working automatically to ensure the network connection. The
Device is regarded as oine only when both NIC cards are
disconnected.
●
Load Balance: Two NIC cards share one IP address and work at the
same time to share the network load averagely. When one NIC card
fails, the other card continues to work normally. The Device is regarded
as oine only when both NIC cards are disconnected.
The Device with single Ethernet port does not support this function.
User's Manual
343
