Dahua NVR54-16HP-EI/NVE54-24P-EI

Figure 5-302 POS setting
Step 2 Congure the POS parameters.
Table 5-88 POS parameters
Parameter
Description
POS Name
In the POS Name list, select the POS machine that you want to congures
settings for. Click to modify the POS name.
●
The POS name must be unique.
●
You can enter up to 21 Chinese characters or 63 English characters.
Enable Enable the POS function.
Record Channel
Click to select a channel to record.
Privacy Enter the privacy contents.
Protocol Select a protocol. Dierent machines correspond to dierent protocols.
Connection Mode
Select the connection protocol type. Click , the IP Address window is
displayed.
In the Source IP box, enter the IP address (the machine that is connected to
the Device) that sends messages.
Character Encode Select a character encoding mode.
