15
to the follow
ing sheet for
more informat
ion.
Address
1
2
3
4
5
6
7
8
1
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
O
N
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
……
…………………
…………………
……………………………
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON
14
16
Table of Contents
Default Chapter
2
Table of Contents
2
Important Safeguards and Warnings
6
1 Features and Functio Features and Functions Features and Functio Ns Ns
8
General Intr General Introduction General Intr Oduction
8
Features
8
On-Screen Menu
8
On-Screen Tips
8
Support Multiple Protocols
8
Proportional Pan and Tilt
8
Preset Setup and Recall
8
Auto Scan
9
Auto Touring
9
Auto Pattern
9
Privacy Masking
9
IR Night Vision
9
Action on Alarm
9
Auto Flip
9
Self-Diagnosis
9
Day/Night Mode (B/W & Color Mode)
9
Auto Focus
9
Backlight Compensation
10
Pan Tilt and Zoom
10
Intelligent Location
10
Idle Status
10
Image Flip
10
Specifications
10
Performance Specifications
10
Technical Specifications
11
2 Protocol, Baud Rate, Protocol, Baud Rate, Address Setup Protocol, Baud Rate, Address Setup
13
Protocol and Baud Rate Setup
13
Set Address Dial Switch
14
3 Cable Connection
16
RS485 and Power Cable Connection
16
Alarm Cable Connection
17
System Layout
18
Alarm Connection
19
Keyboard Connection
19
Menu
21
Screen Menu Index
21
Self
22
Main Menu
22
Menu Operation
23
System Information
23
Display Setting
24
Camera Setting
25
Function Setting
28
IR Light Setup
34
Alarm Setup
35
Dome Abnormal Phenomenon Operation
36
Restore to Factory Default Setup
36
PTZ Movement Is Not Smooth
36
Faq
37
Daily Maintenance
37
Problems and Solutions
37
6 Appendix Ⅰ Ⅰ Ⅰ Ⅰ Thunder Proof and Su Appendix Appendix Thunder Proof and Su Thunder Proof and Surge Protection Rge Protection
38
7 Appendix About Rs485 Bus
39
Appendix Toxic or Hazardous Materials or Elements
41
