Dahua Villa Door Station

Quick Start Guide
10
Installation
Model Example 2:
Open the port cover of the VTO, drill screw holes on the wall according to the dimension
of the mounting hole on the rear panel of the VTO.
Complete the cable wiring.
Fix the port cover to the rear panel of the VTO with four screws.
Fix the VTO on the wall with screws.
Dimension (mm [inch])
