Dahua VTO6 Series User Manual

18
Weight
VTO6100C:0.5kg
VTO6000CM:0.8kg
5 Device Port Illustration
Ports of VTO are illustrated in Figure 5- 1 and Figure 5-2.
Figure 5- 1
No.
Port Name
Description
1
Vandal proof switch
When this device is forced to leave
wall, it will generate alarm
sound and report to the
manager center.
2
Network port
Connect to RJ45 port.
3
RS485
May connect to external module,
such as access control extension
module.
4
Power supply port
Connect to 12V DC.
5
Loudspeaker output
It is the sound output of local
loudspeaker.
