Dahua VTO6100C User Manual

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 9
No.
Name
Description
3
IR Fill light
Provides extra IR light for the camera when it
is dark.
4
Light sensor
Detects ambient lighting condition.
5
Call button
Press to call VTH or the management center.
6
Speaker
Outputs audio.
2.4.2 Rear Panel
VTO2101E-P
Table 2-8 Rear panel description
No.
Name
Description
1
Ethernet port
Connects to the network with Ethernet cable.
2
RS-485 ports
See Figure 2-16 and Table 2-9.
3
Cable tray
You can pull the cable through the cable tray.
Connecting cable
Table 2-9 Port description
Name
Description
NO
Normally open port of lock
NC
Normally closed port of lock
COM
Public port of lock
ALARM IN
Reserved for future use

Dahua VTO6100C Specifications

General

Brand	Dahua
Model	VTO6100C
Category	Intercom System
Language	English
